Wire Cutter

Wire Cutter

CW 320HF Wire Cutter FeatureExcellent thermal balance and rigid cast construction to ensure best machining accuracy and durability.U-V axes, with linear guide way for accurate taper cutting. Using direct drive AC servo motors, high precision ball screws on linear guide ways with optional. 005 mm resolution glass scale, assures precise positioning and fast response to cutting conditions.Stainless steel 3-sided worktable and brushed stainless work tank for long endurance and least maintenance.U-V axes with up to  50 mm travel for wide taper angles (maximum 30 in certain thickness). 21% in 100 mm thickness (models CW530 and above).CW 320HF Wire Cutter SpecificationsX, Y axis (mm) : 360x250 U,V,Z travel (mm) : 60x60x220 Max.size of working piece (WxDxH mm) : 800x560x215 Max. weight of
Call Seller for Quote
Model: CW 320HF
Company Information
Name : COMBITECH MACHINERY CO., LTD.
Contact : COMBITECH MACHINERY COMBITECH MACHINERY
Tel : Please login.

CW 320HF Wire Cutter Feature

  • Excellent thermal balance and rigid cast construction to ensure best machining accuracy and durability.
  • U-V axes, with linear guide way for accurate taper cutting. Using direct drive AC servo motors, high precision ball screws on linear guide ways with optional. 005 mm resolution glass scale, assures precise positioning and fast response to cutting conditions.
  • Stainless steel 3-sided worktable and brushed stainless work tank for long endurance and least maintenance.
  • U-V axes with up to  50 mm travel for wide taper angles (maximum 30 in certain thickness). 21% in 100 mm thickness (models CW530 and above).


CW 320HF Wire Cutter Specifications

  • X, Y axis (mm) : 360x250
  • U,V,Z travel (mm) : 60x60x220
  • Max.size of working piece (WxDxH mm) : 800x560x215
  • Max. weight of working piece(kgw) : 300
  • XY feed rate (mm/min) : Max. 800
  • Motor system (axis) : AC Servo Motor
  • Wire diameter range : ø0.15-0.3 (ø0.25)
  • Max.wire feed rate (mm/sec) : 300
  • Wire tension (gf) : 300-2500
  • Max. taper angel (º) workpiece thickness (mm) : ±14.5º/80 (wide-angled nozzle,DA+DB=15mm)
  • Outside dimension(WxDxH mm) : 2800x2100x2100
  • N.W (Including power and coolant system) (kgw) : 2500
  • Coolant tank system (L) : 340
