Stopping Plug

Application Stopping Plug, DSP Series
The DSP stopping plugs are used for
sealing or closing unused threaded entries

in Ex d enclosures for hazardous areas zone
1, 2 and zone 21, 22.

TECHNICAL DATA Stopping Plug, DSP Series
Explosion protection      :    Ex II 2G Ex d IIC Gb
                                  :    Ex II 2D Ex tb A21 IP66
Compliance with           :    ATEX Directive 94/9/EC, std. EN 60079-0/ -1/ -31,
                                       IECEx Scheme, std. IEC 60079-0/ -1/ -31
Certificate                    :    LCIE 13 ATEX 3046 U
                                        IECEx LCIE 13.0028 U
Degree of protection     :    IP66 acc. To EN 60529 / IEC 60529
Ambient temp. (Ta)      :     -20°C to +75°C
(T..) Temperature class of enclosure to which will be connected.
