Reducer, DRH Series Adaptor (Enlarger)

Application Reducer, DRH Series Adaptor
Reducer and Adaptor are provided a means of attachment between dissimilar thread types or thread sizes.

TECHNICAL DATA Reducer, DRH Series Adaptor
Explosion protection      :    Ex II 2G Ex d IIC Gb
                                  :    II 2D Ex tb IIIC Db Ipbb
Compliance with           :    ATEX Directive 94/9/EC, std. EN 60079-0/ -1/ -31,
                                        IECEx Scheme, std. IEC 60079-0/ -1/ -31
Certificate                    :    LCIE 13 ATEX 3046 U
                                        IECEx LCIE 13.0028 U
Degree of protection     :    IP66 acc. To EN 60529 / IEC 60529
Ambient temp. (Ta)       :     -20°C to +75°C
(T..) Temperature class of enclosure to which will be connected.
