ไมโครมิเตอร์ 25-50 mm. ยี่ห้อ MITUTOYO

รายละเอียดสินค้า ไมโครมิเตอร์

  • ไมโครมิเตอร์ ดิจิตอล ระยะวัด 25-50 mm.

SPECIFICATIONS

Order No Range Resolution Accuracy* Parallelism Constant-force device

Mass

293-241-30 25 - 50 mm 0.001mm. 1μm 1μm With ratchet stop

330g



  • Approximately 2.4-year span of battery life has been achieved, thus reducing the inconvenience of replacing the battery.
  • A nonslip surface with raised dots is employed for the frame cover and surface panel to achieve stable handhold measurement.
  • The ratchet thimble mechanism helps to ensure repeatable results by transmitting microvibrations along the spindle to the contact face to provide a constant  measuring force and encourage good contact with the workpiece. The ratchet works from the thimble as well as the peeder so it is always easy to use – even when making measurements onehanded.  The sound of the ratchet provides the user with a sense of confidence and the speeder enables the rapid spindle feed needed when measuring widely different dimensions.
  • Oilproof materials are used in all plastic components.
  • Two types of constant-force devices are available: Ratchet Stop and Ratchet Thimble.



FUNCTIONS

  • Origin point setting (ABS measurement system) : Resets the ABS origin at the current spindle position to the minimum value of the measuring range and switches to ABS mode.
  •  Zero-setting (INC measurement system) A brief press on the ZERO/ABS button sets display to zero at the current  spindle position and switches to the incremental (INC) measuring mode. A longer press resets to the ABS  measuring mode.
  • Hold : Pressing the HOLD button freezes the current value in the display. This function is useful for preserving a measurement in situations of poor visibility where the instrument must be moved away from the workpiece before the reading can be recorded.
  • Data output*4: Models equipped with this function have an output port for transferring measurement data to a Statistical Process Control (SPC) system. *4: Only models with the data output function
  •  Auto power ON/OFF : The reading on the LCD disappears after this instrument is idle for about 20 minutes, but the reading  and measurement mode are retained. Turning the spindle causes the reading to reappear.
  • Error alarm : In case of an overflow on the LCD or a computing error, an error message appears on the LCD, and the measuring function stops.  This prevents an instrument from giving an erroneous reading. Also, when the battery voltage drops to a certain level, the low-battery-voltage alarm annunciator appears well before the micrometer becomes unusable.
  • Function lock*5 : This function allows the ORIGIN (origin point setting) function and the ZERO (zero-setting ) function to be locked to prevent these points being reset accidentally. *5: All-digit preset type only
