Rotary Blowers

HPC Rotary Blowers

Maximum efficiency plays a key role in all rotary blower and exhauster applications, and is achieved by using a blower block that is perfectly suited to the task in hand. HPC KAESER’s comprehensive and diverse range of two- and three-lobe blower blocks ensure there is a highly efficient OMEGA blower to meet every customer’s technical requirements.

A wide control range combined with low energy consumption is vitally important for blower applications. By using a frequency converter, inlet flow can be variably controlled to match actual demand.

Blocks are available in two- or three-lobe designs and will work at pressures to 1000mb and vacuum to -500mbar. The inlet and discharge silencers are designed to be effective at all frequencies and are eminently suited to variable speed machines. The OMEGA Profile high speed design ensures exceptional acoustic performance from the standardised enclosure range.

Higher rotational blower speeds produce high volumetric efficiencies, which in turn lower discharge temperatures and power consumption. The Compact Range ensures all serviceable items are accessed from the front panels of enclosures. As there is no requirement for side access, side-by-side installation of multiple machines demonstrates significant savings in civils costs brochure about by the lowest possible footprint requirements.

Where humidity and temperature are significant factors in the correct operation of a system, HPC can offer a complete range of coolers (air-blast and shell-and-tube) and dryers designed specifically for blower and exhauster applications where lower pressure drop performance is vital.
