Durco Mark 3 Chemical Process Pumps. Heavy-duty casing with integral foot and multi-ribbed discharge flange. Reverse vane impeller standard; open impeller available. SealSentry seal chambers.
Call Seller for Quote
Model: Mark 3 ISO Standard
Company Information
Name : Thai Polymer Supply Co.,Ltd / บริษัท ไทยโพลิเมอร์ ซัพพลาย จำกัด
Contact : ฝ่ายขาย -
Tel : 0275048528

Durco Mark 3  Chemical Process Pumps

Standard  ASME(ANSI) B73.1

Standards
• ISO 2858
• ISO 5199

Operating Parameters
• Flows to 1400 m3/h (6160 gpm)
• Heads to 220 m (720 ft)
• Pressures to 25 bar (365 psi)
• Temperatures from -80°C (-110°F) to 400°C (752°F)

Features
• Heavy-duty casing with integral foot and multi-ribbed discharge flange
• Reverse vane impeller standard; open impeller available
• SealSentry seal chambers
• Accepts multiple seal arrangements
• External micrometer impeller adjustment mechanism
• Standard non-contacting labyrinth seal
• Heavy-duty radial and thrust bearings
• Two-piece bearing housing
• Back pullout design
• IPS Beacon electronic vibration and temperature condition monitor
• Optional ISO 3A power end with lifetime warranty
• CE marked; ATEX compliant; GOST certificate available
